| Product Name | Operating Voltage in Volts | Leakage Current in MicroAmps | Clamp Volts @500 Amps, 8x20usec | Series Resistance in Ohms | Shunt Capacitance in Picofarads | ||
| L-L | L-G | ||||||
| 444/1151/T12 | 12 | 5 | 48 | 24 | 12 | 6000 | |
| 444/1151T25 | 25 | 5 | 80 | 40 | 12 | 3000 | |
| 444/1151T28 | 28 | 5 | 90 | 45 | 12 | 3000 | |
| 444/1151T35 | 35 | 5 | 120 | 60 | 12 | 3000 | |
| 444/1151T50 | 50 | 5 | 160 | 80 | 12 | 1500 | |
| 444/1151T60 | 60 | 5 | 190 | 95 | 12 | 1500 | |
| 3044/3051/T12 | 12 | 5 | 48 | 24 | 12 | 6000 | |
| 3044/3051T25 | 25 | 5 | 80 | 40 | 12 | 3000 | |
| 3044/3051T28 | 28 | 5 | 90 | 45 | 12 | 3000 | |
| 3044/3051T35 | 35 | 5 | 120 | 60 | 12 | 3000 | |
| 3044/3051T50 | 50 | 5 | 160 | 80 | 12 | 1500 | |
| 3044/3051T60 | 60 | 5 | 190 | 95 | 12 | 1500 | |
 |
