Product Name | Operating Line Voltage Max in Volts | Line Current Amps | Leakage Current in MilliAmps | Clamp Volts @3000 Amps, 8x20usec | |||
L-N | L-G | N-G | |||||
120Vac, 1 line, 2 stage, 3 mode | |||||||
587B051 | 150vrms | 5 | 0.5 | 400V | 500V | 500V | |
587B101 | 150vrms | 10 | 0.5 | 400V | 500V | 500V | |
587B151 | 150vrms | 15 | 0.5 | 400V | 500V | 500V | |
587B201 | 150vrms | 20 | 0.5 | 400V | 500V | 500V | |
587B301 | 150vrms | 30 | 0.5 | 400V | 500V | 500V | |
240Vac, 1 line, 2 stage, 3 mode | |||||||
587B062 | 300vrms | 6 | 0.5 | 800V | 1000V | 1000V | |
587B102 | 300vrms | 10 | 0.5 | 800V | 1000V | 1000V | |
587B162 | 300vrms | 16 | 0.5 | 800V | 1000V | 1000V | |
587B202 | 300vrms | 20 | 0.5 | 800V | 1000V | 1000V | |
587B302 | 300vrms | 30 | 0.5 | 800V | 1000V | 1000V |
