Product Name | Operating Voltage in Volts | Leakage Current in MicroAmps | Clamp Volts @500 Amps, 8x20usec | Series Resistance in Ohms | Shunt Capacitance in Picofarads | ||
L-L | L-G | ||||||
dataline, 4 line, 2 stage, 2 mode | |||||||
232B | 25 | 5 | 80 | 40 | 12 | 3000 | |
dataline, 4 line, 2 stage, 3 mode | |||||||
422B | 12 | 5 | 24 | 24 | 12 | 3000 | |
485B | 12 | 5 | 24 | 24 | 12 | 3000 | |
analog loop, 4 line, 2 stage, 3 mode | |||||||
CLPS423B2510 | 25 | 5 | 40 | 40 | 12 | 3000 | |
420LB28 | 28 | 5 | 40 | 40 | 12 | 3000 | |
420LB35 | 35 | 5 | 60 | 60 | 12 | 3000 | |
420LB60 | 60 | 5 | 85 | 85 | 12 | 1500 | |
telephone, 4 line, 2 stage, 2 mode | |||||||
TEL50B | 50 | 5 | 190 | 95 | 12 | 1500 | |
TEL185B | 185 | 5 | 680 | 340 | 12 | 500 | |
high current, 4 line, 2 stage, 2 mode | |||||||
CLPS422B1800 | 18 | 5 | 70 | 35 | 0.25 | 3000 | |
high current, 2 line, 2 stage, 2 mode | |||||||
CLPS222B1800 | 18 | 5 | 70 | 35 | 0.125 | 6000 | |
Line Current Max: 100mA, CLPS422B1800 2000 mA, CLPS222B1800 5000 mA |
